Product Details
Key Features
- Construction: All balsa and plywood
- Wing: Bolt-on two-piece with aluminum joiner tube
- Covering: High quality heat shrink covering, color scheme is white and red with dark and light blue accents
- Canopy: Clear, painted pilot bust
- Engine Mount: Two-piece composite plastic
- Motor Mount: Plywood
- Spinner: Red plastic 2.3″ (58mm)
- Landing Gear: Main-prebent wire, nose gear-steerable prebent wire with three 2.5″ (63.5mm) treaded wheels
- Fuel Tank: Approximately 12oz (354cc)
In The Box
- ARF Tiger 3 Aerobatic Airplane with Fuel Tank, Motor Mount, Engine Mount, Landing Gear, Spinner, Pilot Bust and Instructions
Needed to Complete
- Radio: 4-channel with five servos
- Glow Power; Engine: .46-.55 cu in (7.5-9.0cc) 2-stroke .52-.61 cu in (8.5cc) 4-stroke Receiver Battery: 4.8-6V / 800-1200mAh NiMH Glow fuel, prop, glow starter
- Electric Power; Brushless Motor: 1000-1400 W, at least 480 KV ESC: 50-70A brushless compatible Battery: 4000-5000mAh LiPo battery Battery Charger: Compatible with selected battery Prop to match selected motor Building and field equipment
Product Specifications
| Wing Loading | 19.66 oz/sq ft (60 g/sq dm) |
| Completion Level | Almost Ready-To-Fly |
| CG (Center of Gravity) | 2.9 – 3.3″ (75 – 85mm) back from the leading edge of the wing at the fuselage |
| Power Type | Electric/Gas |
| Servos | Sold Separately |
| Skill Level | Level 3 |
| Wingspan | 63″ (1600 mm) |
| Radio | Sold Separately |
| Airfoil Shape | NACA |
| Material | Wood |
| Speed Control | Sold Separately |
| Wing Area | 42.8 sq dm (662 sq in) |
| Battery | Sold Separately |
| Product Length | 53.5″ (1359 mm) |
| Charger | Sold Separately |
| Receiver | Sold Separately |
